Technical Data:
Product Type: 64mm Jaw with Integrated Gripper Row
Configuration: Movable
Size: 125
Weight: 1.5kg
Clamping Range T-Rex S1: 11-72mm
Clamping Range T-Rex S2: 93-170mm
Clamping Range T-Rex S3: 51-106mm

Application:
For rectangular sawn workpieces with parallelism <=0.5mm. Rigid design prevents vibration when parts are clamped upright. Additional clamping surfaces are ground on both sides. For five-sided machining with high accessibility.

Dimensions:
A=35mm
B=96mm
B1=64mm
C=12mm
D=14mm
H=35mm
H1=52mm
H2=55mm
L=62.5mm
L1=3mm
L2=7mm

Remark:
For CentroGripp and TeleSense 125, the movable jaw is required twice.

Optional:
Click Parallels Art.No. 6921535035042
