Description
Spade drill base body.
Parallel shank, with through-coolant.

Product Data
Product type: Spade drill base body
Drilling depth: 5xD
Body size: 48
Diameter range Dc: 48-65 mm
L1: 231.8 mm
Shank diameter Dia. Ds: 40 mm
Shank length Ls: 70 mm
Clamping screw: 232990 TX20

Application
For holes up to IT10 accuracy.
Use with HOLEX drill inserts for flat drills.

Note
Further sizes available on request.
