Technical Data:
Clamping pot with monitoring valve
Clamping pot size: Dia. 138 mm (5.4 inch)
With orientation: No
Repetition accuracy: <0.0025 mm
Clamping force: 40 kN (9000 lbf)
Weight: 2.85 kg (6.28 lbs)
Pneumatic monitoring of support and clamping-mechanism position via dynamic pressure
Suitable for automation

Application:
For secure clamping with monitoring of both component/fixture support and clamping-mechanism position.

Remark:
A ZEROCLAMP control unit is recommended for monitoring.
The control unit can connect to machine control and sealing air in an automated version.
